moxie sphinx cat

Moxie

a programming language without fluff

"Perfection is achieved, not when there is nothing more to add, but when there is nothing left to take away." - Antoine de Saint-Exupery

Saint-Exupery was an aircraft engineer. Software is like aircraft - what fails in the air is usually needless complexity.

A compiled systems language for domain-isolated event-driven programs. Each program is a tree of domains - isolated OS processes communicating through serialized IPC channels. No goroutines, no shared memory, no data races.

Moxie descends from TinyGo. All embedded targets and threading infrastructure have been stripped. What remains is a compilation pipeline for Linux, Darwin, and browser JS, rewired for single-threaded domains with process-level isolation via spawn.

Axioms

Everything in Moxie derives from two axioms. They are stated, justified, and expanded into thirty lemmas in [docs/axioms.md](docs/axioms.md), which is the normative document: where any other document appears to conflict with it, the axioms win.

A1 - just the facts. Every property that governs execution is declared and statically checkable. Nothing that determines behaviour is inferred, negotiated, or discovered at runtime.

A2 - total isolation. No component can address another component's state, and every fact has exactly one authoritative owner. State has one owner; interfaces have two.

The operational test: a proposed feature must name the axiom that forces it. If neither axiom forces it, it is an opinion, and it is deleted.

Every rule below is a consequence of those two. Where a section states a rule, it is a lemma from docs/axioms.md.

Quick Start

Prerequisites

LLVM 22 is pinned across the stack: clang, ld.lld, llvm-link, opt and llvm-extract must all be major version 22, and the legacy bootstrap compiler links libLLVM-22. Go 1.25+ is needed only to build that bootstrap compiler.

Most distributions ship LLVM 22 as the unversioned toolchain, so:

# Arch
sudo pacman -S llvm clang lld

# Fedora / RHEL
sudo dnf install llvm clang lld

# Debian / Ubuntu (use apt.llvm.org if your release predates LLVM 22)
sudo apt install llvm-22 clang-22 lld-22

build.sh verifies the major version of every tool before building, so a mis-provisioned machine fails immediately with a list of what is wrong.

See docs/building.md for the full dependency list, per-distribution instructions, and the bootstrap protocol.

# Build the compiler
./build.sh

# Build a program
export MOXIEROOT=/path/to/moxie
moxie build -o hello .
./hello

package main

import "moxie"

func worker(n moxie.Int32) {
    println("child domain:", n)
}

func main() {
    spawn(worker, moxie.Int32(42))
    println("parent continues")
}

The Model

Each domain runs a single thread. No goroutines, no scheduler, no task switching.

The tree of domains is the consequence of A2 (total isolation) and A1 (just the facts): spawn is the only construct that creates a peer, so the topology is a declared and statically checkable artifact (lemma L20).

Construct	Behavior
Unbuffered channel send	Execution jumps to the waiting `select` case
Buffered channel send	Message queued for the next `select` iteration
`select`	Event handler - blocks until a channel, I/O event, or timer fires
`spawn`	Creates a child domain (OS process) with IPC channels

Within a domain, channels and select are the event dispatch system. Between domains, spawn and IPC channels provide concurrent execution with complete memory isolation.

Type Unification

Traditional	Moxie	Effect
`string` (immutable) / `[]byte` (mutable)	`string = []byte`	Same type, mutually assignable. `\\|` for concatenation.
`int` (platform-sized)	`int32` always	32-bit on all targets.

Spawn Boundary

spawn is a language builtin. All data arguments must implement moxie.Codec for serialization. No pointers, functions, or interfaces cross the boundary. Non-constant values are moved (ownership transfer).

import "moxie"

type Codec interface {
    EncodeTo(w io.Writer) error
    DecodeFrom(r io.Reader) error
}

Built-in codec types: Bool, Int8, Uint8, Int16, Uint16, Int32, Uint32, Int64, Uint64, Float32, Float64, Bytes. Little-endian default. Big-endian aliases (BigInt32, BigUint64, etc.) for network protocols.

Removed Features

Removed	Use Instead
`go f()`	Channels + `select`, or `spawn`
`new(T)`	`&T{}`
`+` on text	`\\|` pipe operator
`fallthrough`	`case A, B:`
`complex64/128`	Not supported
`uintptr`	Explicit pointer types
`import "strings"`	`import "bytes"`

Spawn Channel Model: Shared Rings, Non-blocking Duplex

A spawn-bound channel is a pair of shared single-producer single-consumer ring buffers, one per direction, created with mmap(MAP_SHARED) before fork so both processes map the same physical memory. There is no socketpair and no pipe in the channel transport. Each direction has exactly one writer and one reader (lemma L12), which is what makes the ring sound without locks.

The ring is a 32MB data area per direction, lazily faulted, so the virtual reservation is cheap and no frame within ringMaxMsg can silently truncate.

Both directions always exist. The two sides are symmetric concurrent peers, and neither can freeze the other. Backpressure is expressed by ring occupancy, never by a sender blocking in a syscall (lemma L21: the index word is both the state and the notification).

Control rides the same shared memory rather than a separate channel:

channel close - the ring header's closed flag (ringClose)
child readiness - a shared control block's ready atomic, which the parent spins on for the synchronous spawn rendezvous
child death - waitpid on the parent side, getppid on the child side (an orphaned child observes the change and exits)

ChanID convention

chanID 0 = control (close signals), chanID 1 = first spawn channel arg, chanID 2 = second, etc.

Channel operations on spawn channels

Operation	Behavior
`ch <- v`	Encode, `ringSend`, retry-and-yield on backpressure. Returns false on close or peer death.
`v := <-ch`	`ringRecv`, retry-and-yield while empty. Returns `ok = false` on close or peer death.
`select { case v := <-ch: }`	Non-blocking poll via `tryPipeRecv`/`tryPipeSend`, which must never block.
`close(ch)`	`ringClose` on both rings; the peer observes the closed flag on recv and on send.

Targets

Target	Output	Memory
linux/amd64	Static ELF	Arena allocator
linux/arm64	Static ELF	Arena allocator
darwin/amd64	Mach-O	Arena allocator
darwin/arm64	Mach-O	Arena allocator
js/wasm	JavaScript + runtime	Bump allocator

All native binaries are fully statically linked.

AI-Assisted Development

EXAMPLE_CLAUDE.md is a CLAUDE.md template that teaches Claude (or other AI coding assistants) how to write correct Moxie code. Drop it into your project's CLAUDE.md to get accurate code generation that respects Moxie's restrictions and patterns.

Documentation

[docs/axioms.md](docs/axioms.md) - The two axioms, their justification, and the derived lemmas (normative)
[REFERENCE.md](REFERENCE.md) - Complete language specification
[TUTORIAL.md](TUTORIAL.md) - Learn Moxie from scratch
[EXAMPLE_CLAUDE.md](EXAMPLE_CLAUDE.md) - AI coding assistant configuration
[Architecture Patterns](docs/MOXIE_ARCHITECTURE_PATTERNS.md) - CSP/Actor/DDD design patterns and worked examples
[Ownership](docs/OWNERSHIP.md) - Memory ownership model and design principles
docs/spawn.md - Spawn quick reference
docs/architecture.md - Compiler pipeline and runtime internals
docs/restrictions.md - Active restrictions and exemptions
docs/PORTING.md - Migrating existing code to Moxie
docs/building.md - Build instructions and flags

Actor Libraries

The architecture patterns document describes a general CSP/Actor model that applies beyond Moxie. Three libraries implement the intra-domain actor patterns (sections 3.1-3.6) for other languages:

[actor](https://git.smesh.lol/actor) (Go) - go get git.smesh.lol/actor
[pickle](https://git.smesh.lol/pickle) (Rust) - pickle = { git = "https://git.smesh.lol/pickle" }
[anneal](https://git.smesh.lol/anneal) (TypeScript) - npm install anneal

Project Structure

moxie/
├── _mxc_stage4/             # Self-hosting compiler (Moxie source)
├── compile/                 # Compiler library (forward-ported from stage4)
├── build.sh                 # Bootstrap build script
├── release.sh               # Release tarball builder
├── install.sh               # Remote install script
├── jsruntime/               # JS host shims for WASM target
├── sysroot/                 # Precompiled runtime bitcode, musl, compiler-rt
├── src/                     # Target-side sources (compiled INTO programs)
│   ├── runtime/             # Runtime: scheduler, channels, arena, spawn, stringers
│   ├── internal/task/       # Cooperative task system, context switching
│   ├── moxie/               # Codec interface, built-in codec types
│   └── ...                  # Stdlib (.mx files)
└── docs/                    # Language reference, porting guide, architecture
